QuikFlex™ CP

Quikflex CP for Fully Enclosed cartons

Our fully enclosed line of cartoners can be supplied in either continuous or intermittent motion to suit a variety of applications and line configurations. Our line of cartoners is flexible, enables quick changeovers and is designed to erect and seal cartons for totally enclosed packages.

These machines are designed to handle a full range of cartons; from 1-1/2” to 11” wide x 4-1/4” to 13” long x 1-1/2” to 7” deep.

Benefits

Reciprocating, rotary or segment wheel feeding for reliable carton staging

Servo controlled for ease of adjustment

Designed to handle a full range of cartons

Specifications

Machine Features

• Reciprocating, rotary or segment wheel feeding for reliable carton staging
• Servo controlled for ease of adjustment
• Carton Closing: Nordson Hot melt glue system or mechanical carton closure
• No tool changeover
• Allen Bradley electrical package
• Color touchscreen HMI and light tower for visual display of machine functions
• Scales and dial indicators for accurate changeovers
• External Ethernet port for convenience

Speed

• Speeds range from 30 ppm for intermittent motion and up to 200 cartons per minute for continuous motion (depending upon product size and characteristics)

Product Configuration

• Single or multi layer of product

Machine Models

• Intermittent motion or continuous motion

Electrical and Air Requirements

• Control Voltage: 24 VDC
• Supply Voltage: 480 VAC, Three Phase, 60 HZ
• 80 psi clean/dry air supply required (equivalent to class 3 or better)
• CFM dependent on vacuum system specified





Seal End Carton
