AutoClip™ KC1600

Based on the highly efficient product-pitched Marksman™ 1600 product line, the AutoClip™ KC1600 is a high-speed system that applies that KeelClip™ premium clip-style fastener to multipacks of two-piece beverage cans.

KeelClip replaces plastic rings and shrink film and offers merchandising benefits that other similar beverage packaging can’t, including can orientation and maximum billboarding space.

The AutoClip KC1600 machine is highly flexible and can accommodate all sizes of beverage cans.

When used in combination with ClipCombo™ technology, beverage makers can run multiple fiber-based multipack styles across the same machine, delivering real value and flexibility to meet today’s and tomorrow’s needs.

AutoClip™ KC1600

AutoClip KC1600 Benefits

Operational Efficiency Benefits
Operational Efficiency
  • Robust construction thanks to a heavy-duty tubular steel frame with corrosion-resistant coatings and materials
  • Clear visibility and sliding guard doors for easy walk-in access
  • Fewer parts, adjustments, chains, and drive points, and simpler timing
  • Improved accessibility and better carton control from the feeder to the discharge
  • Our market-proven predictive maintenance program (PMP) helps plan downtime and enables better budgeting
Convenience Benefits
  • Quick, simple, and repeatable tool-free changeovers
  • IQ tablet provides changeover checklist and video guidance
  • Changeover time of 12-90 minutes

See the AutoClip KC1600 in Action


  • Product orientation turrets
  • One per lane to orient cans
  • Integrated turner divider reject system
  • Glue detection
  • 10ft (3.2m) standard magazine
  • Approx. 4500 carton capacity
  • 10ft (3m) laned product infeed conveyor
  • Segment wheel feeder

AutoClip KC1600 Specifications

Primary Containers
  • Two-piece beverage cans only
  • Diameter: 2.09” (53mm) to 2.6” (66mm)
  • Height: 3.11” (79mm) to 7.44” (189mm)
  • Standard: fixed, single diameter, multiple heights
  • Optional: multi-diameter
Pack Styles and Formats
  • Pack styles: KeelClip and KeelClip G2 packs
  • Pack formats: Standard: 2×2, 2×3, 2×4, 2×5
Speed* and Pitches
  • Format 2×2 | line 350ppm | surge 400ppm
  • Format 2×3 | line 330ppm | surge 350ppm
  • Format 2×4 | line 240ppm | surge 260ppm

    * Speeds are dependent upon container size and configuration.
Product Configuration and Size
Machine Dimensions
  • Dimension: 49’ – 7 3/4” (15.13m)
  • Standard machine elevation: 43.5” +/-2” (1100mm +/- 50mm)
Machine Weight
  • Approximately 20,000lbs (9,000kg)
